Sansui 9090DB receiver – Fully restored/Recapped/LEDS upgraded-1 year WRT

Sansui 9090DB receiver – Fully restored/Recapped/LEDS upgraded-1 year WRT

This listing features a lightly-used Sansui Stereo 9090DB AM/FM Receiver, professionally serviced, tested, and guaranteed. The cabinet is beautiful with very, very light blemishes & the faceplate is in perfect condition. With the sleek design and powerful features, this item will be sure to enhance any audio setups. It includes transistor and capacitor upgrades, a full LED upgrade, a new FM dipole antenna, and complimentary 1-year protection.

💪 High Power Output: Delivers a robust 125 watts per channel at 8 ohms, ensuring exceptional performance for any audio setup.

🔧 Fully Restored & Recapped: Professionally serviced with premium components to ensure peak performance and reliability.

✨ Upgraded LEDs: Modern LED lighting enhances the display while reducing heat and energy consumption.

🎵 Unmatched Sound Quality: Warm, rich tones and dynamic range make it perfect for any music genre.

🪞 Timeless Design: Features a brushed aluminum faceplate, detailed analog meters, and a beautifully crafted wooden cabinet.

🔗 Multiple Inputs: Phono, AUX, tape, and FM/AM connections for versatile compatibility.

TESTING VIDEO

Technical Specifications:

• Tuning range: FM, MW
• Power output: 110 watts per channel into 8Ω (stereo)
• Frequency response: 10Hz to 30kHz
• Total harmonic distortion: 0.2%
• Damping factor: 10
• Input sensitivity: 2.5mV (MM), 100mV (DIN), 100mV (line)
• Signal to noise ratio: 70dB (MM), 80dB (line)
• Channel separation: 50dB (MM), 50dB (line)
• Output: 100mV (line), 30mV (DIN), 0.75V (Pre out)
• Dimensions: 540 x 182 x 397mm
• Weight: 23.3kg
• Year: 1975

💥 Own a Vintage Legend! 💥

The Sansui 9090DB Receiver is a classic piece of audio history, offering stunning sound, premium build quality, and timeless design. Don’t miss the chance to own this fully restored masterpiece with upgraded LEDs!

👉 Order now and experience the brilliance of Sansui’s iconic engineering!

#Sansui9090DB #VintageReceiver #RestoredAudio #AudiophileGear #LEDUpgrade #ClassicSound #HiFiAudio #SansuiLegacy

TRADE-IN PROGRAM

“If you have any vintage audio equipment (receivers, speakers, cassette, reel to reel…) & want to upgrade with the available serviced one, don’t hesitate to contact us for the best deal. You only need to pay for the difference”

Condition:

This receiver is in “Excellent” condition, displaying minor signs of use with a bright, clear dial. All knobs, feet, and the attached AM antenna and AC cord are present and intact. Although the manual is missing, it can be found online or we can provide a PDF upon request. Please inspect all photos thoroughly for the actual condition.

Service:

Upon inspection, the unit had scratchy controls, a dim dial, and some distortion in one channel. Therefore, it underwent servicing by our technician. Manufacturer used certain transistors in this model that are known to fail after 40 years, so all of these were replaced. This upgrade resolved the distortion issue. Additionally, several questionable capacitors were replaced.

Testing:

After servicing, the receiver was tested on our bench and performed excellently, delivering a powerful, warm, distortion-free signal characteristic of analog receivers. All inputs, outputs, LED lights upgrade and features were confirmed operational, and the tuner spins smoothly. Additional testing was conducted, and we can provide specific feature information upon request. This is a remarkable find for the vintage audiophile.

Condition Disclosure:

This item exhibits minor wear consistent with light use, as shown in the provided photos. The listing includes exactly what is pictured; no accessories, test equipment, or media are included.
