Sansui QRX5500 receiver – Fully restored/Recapped – 1 year warranty

$899

Specification:

  • Condition: Excellent – Refurbished (professionally serviced, tested, and guaranteed)
  • Model: QRX5500
  • Brand: Sansui
  • Protection Plan: 1 year warranty
  • FREE SUPPORT: MUST BE UTILIZED BEFORE RETURN IS REQUESTED
  • Type: Solid-State Stereo Receiver
  • Pro packaged, insured and includes tracking.
  • No Boxes, No accessories
  • SKU: 5QPVE0262

1 in stock

SKU: 5QPVE0262 Categories: , , Tags: ,

Sansui QRX5500 receiver – Fully restored/Recapped – 1 year warranty

Uncompromising quality is the key factor in the design concept of the QRX-5500. It’s a full-fledged 4-channel stereo home control center with all the advantages of the very latest electronic technology in the form of its all-stage direct-coupled OCL pure complementary power amplifier. What’s more, it offers excellent performance, high fidelity performance of the highest standards, and Sansui reliability.

✔️ Professional Restoration: All internal components have been carefully inspected, repaired, or replaced to bring this unit to like-new condition.

🛡️ 1-Year Warranty: Shop with confidence knowing your investment is protected.

💎 Vintage Collector’s Dream: A highly sought-after model for audiophiles and collectors, showcasing Sansui’s expertise in quadraphonic sound.

TESTING VIDEO

Technical Specifications:

  • Tuning range: FM, MW
  • Power output: 22W/ch into 8Ω (quadraphonic)
  • Frequency response: 30Hz to 30kHz
  • Total harmonic distortion: 0.3%
  • Damping factor: 40
  • Input sensitivity: 2.5mV (mic), 2.5mV (MM), 100mV (DIN), 100mV (line)
  • Signal to noise ratio: 70dB (MM), 80dB (line)
  • Output: 100mV (line), 30mV (DIN)
  • Speaker load impedance: 4Ω to 16Ω
  • Semiconductors: 136 x transistors, 5 x FET, 80 x diodes, 6 x zener diodes, 3 x IC
  • Dimensions: 203 x 594 x 370mm
  • Weight: 21.6kg
  • Year: 1973

Own a Piece of Vintage Audio History!
The Sansui QRX-5500 is a remarkable blend of beauty and performance, making it a must-have for any serious audio enthusiast. Don’t miss out on this fully restored masterpiece!

👉 Order now and experience the magic of quadraphonic sound!

#SansuiQRX5500 #QuadraphonicReceiver #VintageAudio #RestoredSansui #AudiophileGear #ClassicSound #HiFiAudio

TRADE-IN PROGRAM

“If you have any vintage audio equipment (receivers, speakers, cassette, reel to reel…) & want to upgrade with the available serviced one, don’t hesitate to contact us for the best deal. You only need to pay for the difference”

Condition:

This receiver is in “Excellent” condition, displaying minor signs of use with a bright, clear dial. All knobs, feet, and the attached AM antenna and AC cord are present and intact. Although the manual is missing, it can be found online or we can provide a PDF upon request. Please inspect all photos thoroughly for the actual condition.

Service:

Upon inspection, the unit had scratchy controls, a dim dial, and some distortion in one channel. Therefore, it underwent servicing by our technician. Manufacturer used certain transistors in this model that are known to fail after 40 years, so all of these were replaced. This upgrade resolved the distortion issue. Additionally, several questionable capacitors were replaced.

Testing:

After servicing, the receiver was tested on our bench and performed excellently, delivering a powerful, warm, distortion-free signal characteristic of analog receivers. All inputs, outputs, LED lights upgrade and features were confirmed operational, and the tuner spins smoothly. Additional testing was conducted, and we can provide specific feature information upon request. This is a remarkable find for the vintage audiophile.

Condition Disclosure:

This item exhibits minor wear consistent with light use, as shown in the provided photos. The listing includes exactly what is pictured; no accessories, test equipment, or media are included.

Thank you for being a valued customer & Thanks for looking!
