Marantz 2230B receiver

Marantz 2230B receiver-Fully Restored/1year WRT (free to choose WCs colors)

Specification:

• Condition: Excellent – Refurbished (professionally serviced, tested, and guaranteed) + Wooden Cabinet, Pro Packaged
• MODEL:  2230B
• Brand: MARANTZ
• Protection Plan: 1 year warranty
• Band: Radio/AM/FM
• FREE SUPPORT: MUST BE UTILIZED BEFORE RETURN IS REQUESTED
• Type: Stereo Receiver
• Pro packaged, insured and includes tracking.
• SKU: 5QJKE4008

Marantz 2230B is a celebrated vintage stereo receiver, known for its superior sound quality and timeless design. Ideal for audiophiles and vintage audio enthusiasts, this receiver offers a warm, rich sound that modern digital receivers often struggle to match. Its robust construction and classic aesthetics make it a standout addition to any audio setup.

TESTING VIDEO

Detailed Specifications

• Power Output: 30 watts per channel into 8 ohms
• Frequency Response: 20 Hz – 20 kHz
• Total Harmonic Distortion: 0.1%
• Signal-to-Noise Ratio: 90 dB (line), 70 dB (phono)
• Dimensions: 17.5 inches (W) x 14 inches (D) x 5.5 inches (H)
• Weight: 26 lbs
• Inputs: Phono, Aux, Tape Monitor
• Outputs: Speaker A/B, Headphone Jack
• Tuner: FM/AM with Signal Strength and Tuning Meters

TRADE-IN PROGRAM

“If you have any vintage audio equipment (receivers, speakers, cassette, reel to reel…) & want to upgrade with the available serviced one, don’t hesitate to contact us for the best deal. You only need to pay for the difference”

Condition:

This receiver is in “Very Good” condition, displaying minor signs of use with a bright, clear dial. All knobs, feet, and the attached AM antenna and AC cord are present and intact. Although the manual is missing, it can be found online or we can provide a PDF upon request. Please inspect all photos thoroughly for the actual condition.

Service:

Upon inspection, the unit had scratchy controls, a dim dial, and some distortion in one channel. Therefore, it underwent servicing by our technician. Manufacturer used certain transistors in this model that are known to fail after 40 years, so all of these were replaced. This upgrade resolved the distortion issue. Additionally, several questionable capacitors were replaced.

• All Service Bulletins performed.
• Electrolytic capacitors replaced throughout.  (Filter caps and tuner caps unchanged – tested and found within specification.)
• New relay
• All switches (removed and opened), selectors and potentiometers cleaned
• Troublesome transistors/diodes replaced where necessary
• Fully tested. Fully functional

Testing:

After servicing, the receiver was tested on our bench and performed excellently, delivering a powerful, warm, distortion-free signal characteristic of analog receivers. All inputs, outputs, LED Light upgrade, and features were confirmed operational, and the tuner spins smoothly. Additional testing was conducted, and we can provide specific feature information upon request. This is a remarkable find for the vintage audiophile.

Condition Disclosure:

This item exhibits minor wear consistent with light use, as shown in the provided photos. The listing includes exactly what is pictured; no accessories, test equipment, or media are included.

Thank you for being a valued customer & Thanks for looking!
